If the item is in stock PMC can ship same day when ordered Monday-Friday; inquiries made on weekends or holidays are addressed the next business day
AEMC Model 8510 Digital Transformer Ratiometer
The DTR® Model 8510 is a portable digital transformer ratiometer designed for on-site testing of power, potential and current transformers. When connected to a non-energized transformer, the DTR® Model 8510 accurately measures primary to secondary turns ratio, while simultaneously displaying polarity and excitation current. The DTR® is fully automatic and uses an ANSI/IEEE compliant test method. No user calibration, range selection, hand cranking or tedious balancing is required. At each measurement, the DTR® automatically self-calibrates and checks for open windings/connections/circuit breakers, short circuits (excess excitation current), incorrect test lead placement, and reverse polarity. Measurements are displayed quickly and accurately.
Features:
• Ratio Testing: PT/VT from 0.8000:1 to 8000:1 and CT from 0.8000 to 1000.0 (Auto-Ranging)
• Tests performed by exciting the primary and reading the secondary; provides safer conditions for the operator on step-down transformers
• Continuity test indicates open or loose (high resistance) terminal connections
• DC test mode eliminates errors due to magnetic build up
Transformer Testers
