If the item is in stock PMC can ship same day when ordered Monday-Friday; inquiries made on weekends or holidays are addressed the next business day
Megger CFL510F Time Domain Reflectometer
The MEGGER CFL510F is an advanced instrument capable of identifying a wide range of cable faults using Time Domain Reflectometry. It offers exceptional features and a range capability normally associated with larger, more expensive instruments. The measurement range spans from 30 feet to9,000 feet, with a minimum resolution of four inches.
The Model CFL510F can be used on any cable consisting of at least two insulated metallic elements, one of which may be the sheath or shield of the cable. The CFL510F has internal matching networks to allow testing of 25-, 50-, 75-, and 100-Ω cables. (These correspond to power, cellular, CATV, and telephone cable). The FastFind key simplifies waveform interpretation by automatically adjusting the instrument's range and gain and places the measurement cursor at the major event on the cable.
The instrument can be closely matched to the cable using the balance control allowing long lengths of cable to be easily tested and faults close to the instrument accurately measured. The propagation velocity value can be similarly adjusted to match the cable; thus ensuring an ac-curate distance measurement. To en-able a wider range of faults to be detected, the gain of the instrument is also adjustable which helps the user identify minor faults over the entire cable length.
Cable Locators and Fault Finders
